The Motion Detector

Kind of like a camera (but less creepy)

All home automation and security systems should have a few Motion Detectors. They will let you know if someone is walking around where they shouldn't be, or they can automagically turn lights on when you enter the room. The built-in ambient light sensor adds another layer of awesome to the automation possibilities, and you can install it practically anywhere.






Motion Detector Usage Ideas





Secure Your Home

Place Motion Detectors in your living room and other spaces with windows, and configure your Hub to send a notification or automatically trigger a Siren when motion is detected at unusual times.


Be Green and Stuff

Turn off lights when nobody is around! Install the Motion Detector in common living spaces and set up your Hub to turn off the lights if the room is empty for more than fifteen minutes.


Brighten Up

Automatically turn on lights when you enter a room or hallway, and use the ambient light sensor to dim them to the perfect brightness level.




Features

icon

Adjustable Sensitivity

Customize the device for your room and application.

icon

Battery Powered

So it can be installed anywhere without any wires or power outlet.

icon

Extra Wide 110° Detection

Large detection area to monitor
entire rooms.

icon

Built-in Light Sensor

Monitor the surrounding light levels to automate lighting.

icon

Low Profile

Its small footprint means it stays out of the way.


icon

Mounting Versatility

Use on walls, tabletops, ceilings, and other surfaces.





Spec/Info

Technical Data

Power supplySingle CR123A 3.0V battery

Working current35mA

Power Consumption0.15W

Operating temperature32 - 104 °F (0 - 40 °C)

Mounting OptionsWall, tabletop, shelftop

WarrantyOne Year Parts & Labor

Sensor Dimensions1.75” Sphere

Z-Wave Info

Raido ProtocolZ-Wave(500 series)

Radio Frequency908.4 MHz US

CapabilitiesNotifications(Home Security)
Multilevel Sensor (Lux)
Controllable LED



RangeUp to 150’ depending on environment

Resources

User Manual (PDF)

Advanced Manual (Web)

Installation (Web)

Basic Z-Wave Usage (Web)

Command Classes (Web)

Configuration Parameters (Web)

Package Contents

User Manual

Sensor

Sensor Mount

Battery

2x Screws

2x Wall Anchors





Not finding your answers in the Docs or FAQ's? Shoot us a support ticket and we'll reply right away.

As former installers we know how important clean, easy to read documentation is. We created Dome from the ground up with the idea that sensors should work with any hub, and they should be easy to modify and troubleshoot.
